DO-41P Axial Lead Plastic Package

STANDARD RECOVERY RECTIFIERS

Application General-Purpose Low-Power

Note: This device is also available in Defence/Miltary, HIREL and JANXXX grades.

Device Types

1N4001 50V/1A

1N4002 100V/1A

1N4003 200v/1A

1N4004 400V/1A

1N4005 600V/1A

1N4006 800V/1A

1N4007 1000V/1A

See the data sheet for 1N4001 ~ 1N4007

DO-41 Axial Lead Plastic Package

SCHOTTKY BARRIER RECTIFIERS

Application Low Voltage, High Frequency

Inverters, Free Wheeling Diodes and Polarity Protection Diodes

NOTE : This device is also available in Defence, HIREL grade, JANXXX, Miltary Grades

Device Types

1N5817 20V,1.0A

1N5818 30V,1.0A

1N5819 40V,1.0A

See the data sheet for 1N5817 1N5818 1N5819

DO-201AD (DO-27) Axial Lead Plastic Package

FAST RECOVERY RECTIFIERS

Applications Fast switching for high efficiency.

Note: This device is also available in Defence/Miltary, HIREL and JANXXX grades.

Device Types

BY396 BY397 BY398 BY399

FR301 FR302 FR303 FR304 FR305 FR306 FR307

50V 100V 200V 400V 600V 800V 1000V

3.0A 3.0A 3.0A 3.0A 3.0A 3.0A 3.0A

See the data sheet for FR3/BY396

DO-41 Plastic Package

FAST RECOVERY RECTIFIERS

Application: fast switching rectification of power supply, inverters, converters and freewheeling diodes for consumer and telecommunication.

Note: This device is also available in Defence, Miltary, Hirel and JANXXX Grades

Device Types

BA157 400V,1A

BA158 600V,1A

BA159 1000V,1A

See the data sheet for BA157 BA158 BA159

DO-35 Hermetically Sealed Glass Axial Package

These devices are also available in SOT-23 (SMD Plastic Package) equivalents as BZX84C Series

NOTE : This device is also available in Defence, HIREL grade, JANXXX, Military Grades

Device Types

BZX55C 2.4V ~ 75V

Applications: Best suited for Industrial, Military and Space Applications.

See the datasheet for BZX55C Series

DO-41 Axial Leaded Package

1 W Silicon Planar Power Zener Diodes

Device Types
1N4727A ~ 1N4761A 3V to 75V Zener

NOTE : This device has Option for screening as per MIL-PRF-19500 for JAN, JANTX, JANTXV and JANS are available by adding CJ,

CX, CV or CS suffix respectively after the part number while ordering.

See the datasheet for 1N47XXA Series

DO-35 GLASS AXIAL PACKAGE

GENERAL PURPOSE DIODES

Application high speed switching diodes

NOTE : This device is also available in Defence, HIREL grade, JANXXX, Miltary Grades

Device Types

BAV19 100V, 250mA

BAV20 150V, 250mA

BAV21 200V, 250mA

See the data sheet for BAV19 BAV20 BAV21

SOT-23 Formed SMD Package

SILICON PLANAR DUAL SWITCHING DIODES

Application High-Speed Switching Dual Diodes

NOTE : This device is also available in Defence, HIREL grade, JANXXX, Miltary Grades

Device Types

BAW56 75V, 215mA

See the data sheet for BAW56

DO-35 Glass Axial Package

SILICON HIGH SPEED SWITCHING DIODE

Application General purpose, Industrial, Military and Space

NOTE : This device is also available in Defence, HIREL grade, JANXXX, Miltary Grades

Device Types
1N4148/1N4448 100V,200mA

See the data sheet for 1N4148,1N4448

DO-35

SILICON ZENER DIODES

Application Hermetically Sealed Glass Package Zener Diodes

Note : This device is also available in Defence/ Miltary, JanXXX and Hirel grades

Device Types

1N746 3.3V,20mA

1N747 3.6V,20mA

1N748 3.9V,20mA

1N749 4.3V,20mA

1N750 4.7V,20mA

1N751 5.1V,20mA

1N752 5.6V,20mA

1N753 6.2V,20mA

1N754 6.8V,20mA

1N755 7.5V,20mA

1N756 8.2V,20mA

1N757 9.1V,20mA

1N758 10V,20mA

1N759 12V,20mA

See the data sheet for 1N746 to 1N759

DO- 35 Glass Axial Package

SILICON PLANAR ZENER DIODES

Application Reliability and better power dissipation.

Note: This Devices is also available in Defence, Miltary, JanXXX an Hirel Grades.

Device Types

1N5223B_1N5242B 2.7V_12V,20mA

See the data sheet for 1N5223B_1N5242B

DO-35

Silicon Epitaxial Planar Diode

Application Typical applications are in switching power supplies,

NOTE : This device is also available in Defence, HIREL grade, JANXXX, Mil Grades

Device Types
CD282

CD283

CD284

CD285

CD286

See the data sheet for CD282_286

DO-35 Glass Axial Package

SILICON EPITAXIAL PLANAR DIODES (500mW)

Application High Voltage Switching Diodes

NOTE : This device is also available in Defense, HIREL grade, JANXXX, Miltery Grades

Device Types

CT 21 TO CT186 20V TO 250V

See the data sheet for CT21 TO CT186

DO-35 Glass Axial Package

HIGH SPEED SILICON SWITCHING ZENER DIODE AXIAL LEAD (500mW)

Application Industrial Purpose , Military & Space applications.

NOTE : This device is also available in Defence, HIREL grade, JANXXX, Miltary Grades

Device Types

CTZ 2.6V ~ 47V 2.6V to 47V

See the data sheet for CTZ 2.6V ~ 47V

TO-18 Metal Can Package

NPN SILICON PLANAR SWITCHING TRANSISTORS

Applicaton Switching And Linear Application DC And VHF Amplifier

NOTE : These devices are also available in Defence, HIREL and Miltary Grades

Device Types
2N2221A,22A 40V,800mA

See the data sheet for 2N2221A 2N2222A

TO-39 Metal Can Package

NPN SILICON PLANAR SWITCHING TRANSISTORS

Application Switching And Linear Application

NOTE : This device is also available in Defence, HIREL grade, JANXXX, Miltary Grades

DC And VHF Amplifier

Device Types
2N2218A,19A 40V,800mA

See the data sheet for 2N2218A/2N2219A

TO-39 Metal Can Package

NPN HIGH VOLTAGE SILICON TRANSISTORS

Application High Voltage & High Power Amplifier

NOTE : This device is also available in Defence, HIREL grade, JANXXX, Miltary Grades

Device Types
2N3439 350V,1.0A
2N3440 250V,1.0A

See the data sheet for 2N3439 2N3440

TO-18 Metal Can Package

PNP Silicon Planar Transistor

Application Amplifier Transistor

Note: This device is also available in Defence, Miltary, Hirel and JANXXX Grades

Device Types
2N3505 60V, 0.6 Amp

See the data sheet for 2N3505

TO-39 Metal Can Package

NPN Silicon Planar Transistor

Application Amplifier Transistor

Note: This device is also available in Defence, Miltary, Hirel and JANXXX Grades

Device Types
2N2107 60V, 0.5 Amp

See the data sheet for 2N2107

TO-39

PNP SILICON PLANAR TRANSISTORS

Application General Purpose Amplifiers,Switching

Note: This device is also available in Defence/Miltary, HIREL and JANXXX grades.

Device Types
2N4234 40V,1.0A

2N4235 60V,1.0A

2N4236 80V,1.0A

See the data sheet for 2N4234, 2N4235 2N4236

TO-18 Metal Can Package

NPN SILICON PLANAR TRANSISTORS

Application Low Noise General Purpose Audio Amplifiers

NOTE : This device is also available in Defence, HIREL grade, JANXXX, Miltary Grades

Device Types

BC107 45V, 200mA

BC108 25V, 200mA

BC109 25V, 200mA

See the data sheet for BC107/A/B/C BC108/A/B/C BC109/A/B/C

TO-39 Metal Can Package

NPN SILICON POWER SWITCHING TRANSISTORS

Application Medium Power Amplifier and Switching

Note: This device is also available in Defence, Miltary, Hirel and JANXXX Grades

Device Types

BC140 40V, 1.0A

BC141 60V, 1.0A

See the data sheet for BC140, BC141

TO-39 Metal Can Package

PNP SILICON POWER SWITCHING TRANSISTORS

Application Medium Power Amplifier and Switching.

Note: This device is also available in Defence, Miltary, Hirel and JANXXX Grades

Device Types

BC160 40V, 1.0A

BC161 60V, 1.0A

See the data sheet for BC160, BC161

TO-18 Metal Can Package

PNP SILICON PLANAR TRANSISTORS

Application Low Noise General Purpose Audio Amplifiers

NOTE : This device is also available in Defence, HIREL grade, JANXXX, Miltary Grades

Device Types :

BC177 45V, 200mA

BC178 25V, 200mA

BC1 79 20V, 200mA

See the data sheet for BC177 BC178 BC179 A/B/C

TO-39 Metal Can Package

NPN SILICON PLANAR SWITCHING TRANSISTORS

Application Medium Power Amplifier and Switching

Note: This device is also available in Defence/Miltary, HIREL and JANXXX grades.

Device Types :

2N1481 40V 1.5A

2N1482 55V 1.5A

See the data sheet for 2N1481, 2N1482

TO-39 Metal Can Package

NPN SILICON PLANAR TRANSISTOR

Application General Purpose Transistor

Note : This device is also available in Defence/ Miltary, JanXXX and Hirel grades

Device Types

2N1711 50V, 300hFE

See the data sheet for 2N1711

TO-39 Metal Can Package

NPN SILICON PLANAR TRANSISTORS

Application Amplifier Transistor

This device is also avilable in Defence/ Hirel, JANXXX and Miltary grades

Device Types

2N2270 45V, 1.0A

See the data sheet for 2N2270

TO-39 Metal Can Package

NPN SILICON PLANAR TRANSISTOR

Application General Purpose Transistor

Note : This device is also available in Defence/ Miltary, JanXXX and Hirel grades

Device Types

2N2405 90V, 1A

See the data sheet for 2N2405

TO-39

PNP SILICON PLANAR SWITCHING TRANSISTORS

Application Switching And Linear Application

NOTE: This device is also available in Defence/ Miltary, HIREL, JANXXX Grades

Device Types

2N2904A 2N2905A 60V, 600mA

See the data sheet for 2N2904A 2N2905A

TO-39 Metal Can Package

NPN SILICON PLANAR TRANSISTOR

Application General Transistor

NOTE: These devices are also available in Defence, HIREL, JANXXX, Miltary Grades.

Device Types

2N3019 / 2N3020 80V, 1.0A

See the data sheet for 2N3019 2N3020

TO-18 Metal Can Package

PNP SILICON PLANAR SWITCHING TRANSISTORS

Application  General Purpose and Switching

Device Types
2N3250   2N3250A    40V, 200mA

2N3251   2N3251A    60V, 200mA

See the data sheet for  2N3250, A/ 2N3251,A

TO-39 Metal Can Package

PNP SILICON PLANAR RF TRANSISTORS

Application High Voltage Switching and Low Power Amplifier.

Note : This device is also available in Defence/ Miltary, JanXXX and Hirel grades

Device Types

2N3635 140V, 1A

2N3636, 37 175V, 1A

See the data sheet for 2N3635 2N3636 2N3637

TO-18

NPN SILICON PLANAR EPITAXIAL TRANSISTORS

Application General purpose amplifier.

Note: This device is also available in Defence/Miltary, HIREL and JANXXX grades.

Device Types

2N3700 2N3701 80V, 1.0A

See the data sheet for 2N3700 2N3701

TO-39 Metal Can Package

PNP SILICON PLANAR TRANSISTORS

Application GENERAL PURPOSE AMPLIFIER, TRANSISTORS.

Note: This Device is also available in Defence/Miltary, Hirel, JANXXX Grades

Device Types

2N4030, 2N4032 60V, 1A

2N4031, 2N4033 80V, 1A

See the data sheet for 2N4030, 2N4031 2N4032, 2N4033
