DO-214AA (SMB) SMD Plastic Package

2A SURFACE MOUNT GENERAL PURPOSE RECTIFIER

Applications : GENERAL PURPOSE RECTIFIER

Device Types
S2A 50V,2A
S2B 100V,2A
S2D 200V,2A
S2G 400V,2A
S2J 600V,2A
S2K 800V,2A
S2M 1000V,2A

See the data sheet for S2A_2M

DO-214AC (SMA) SMD Plastic Package

SURFACE MOUNT SCHOTTKY BARRIER RECTIFIERS

Application:

Low Voltage High-Frequency Inverters,

Free Wheeling, and Polarity Protection.

Device Types

SS12 20V/1A
SS13 30V.1A
SS14 40V/1A
SS15 50V/1A
SS16 60V/1A

SS18 80V/1A

SS110 100V/1A

SS115 150V/1A

SS120 200V/1A

See the datasheet for SS12 ~ SS120

KBP Leaded Plastic Package

Device Types
KBP3005 50V/3Amp
KBP301 100V/3Amp
KBP302 200V/3Amp
KBP304 400V/3Amp
KBP306 600V/3Amp
KBP308 800V/3Amp
KBP310 1000V/3Amp

See the data sheet for KBP3XX10 Series

KBL Leaded Plastic Package

Device Types
KBL005 50V/ 4Amp
KBL01 100V/ 4Amp
KBL02 200V/ 4Amp
KBL04 400V/ 4Amp
KBL06 600V/ 4Amp
KBL08 800V/ 4Amp
KBL10 1000V/ 4Amp

See the data sheet for KBL005_ KBL10

DO-41P Axial Lead Plastic Package

STANDARD RECOVERY RECTIFIERS

Application General-Purpose Low-Power

Note: This device is also available in Defence/Miltary, HIREL and JANXXX grades.

Device Types

1N4001 50V/1A

1N4002 100V/1A

1N4003 200v/1A

1N4004 400V/1A

1N4005 600V/1A

1N4006 800V/1A

1N4007 1000V/1A

See the data sheet for 1N4001 ~ 1N4007

SOT-23

SURFACE MOUNT SCHOTTKY DIODES

Application  Ultra High Speed Switching,circuit protection, and voltage clamping

Device Types
BAS70 70V, 70mA  Single diode

BAS70-04 70V, 70mA Dual Diode

BAS70-05 70V, 70mA Dual Diode Common Cathode

BAS70-06 70V, 70mA Dual Diode Common Anode

See the data sheet for BAS70 BAS70-04 BAS70-05 BAS70-06

A-405 Axial Lead Plastic Package

STANDARD RECOVERY RECTIFIERS

Application General-Purpose Low-Power Applications

Device Types

1N4001S 50V, 1.0A

1N4002S 100V, 1.0A

1N4003S 200V, 1.0A

1N4004S 400V, 1.0A

1N4005S 600V, 1.0A

1N4006S 800V, 1.0A

1N4007S 1000V, 1.0A

See the data sheet for 1N4001S - 1N4007S

DO-214AA (SMB) Surface Mount Package

SURFACE MOUNT SCHOTTKY BARRIER RECTIFIERS

Application :

 Low Voltage, High Frequency Inverters,

Free Wheeling and Polarity Protection

Device Types
SS22   20V,2.0A

SS23   30V,2.0A

SS24   40V,2.0A

SS26   60V,2.0A

SS28  80V,2.0A

SS210  100V,2.0A

SS215 150V,2A

SS220 200V,2A

See the data sheet for :  SS22 ~ SS220SS22 ~ SS220

DO-214AA (SMB) Surface Mount Package

SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER

Application :

A. DC/DC Converters:

B. High-Frequency Inverters:

C. Freewheeling Diodes:

D. Reverse Polarity Protection:

E. Secondary Rectification:

Device Types
SS32   20V,3.0A

SS33   30V,3.0A

SS34   40V,3.0A

SS35   50V,3.0A

SS36   60V,3.0A

SS38   80V,3.0A

SS39     90V,3.0A

SS310   100V,3.0A

SS315 150V, 3A

SS320 200V,3A

See the data sheet for : SS32 - SS320

DO-214AC(SMA) Surface Mount Package

SURFACE MOUNT ULTRAFAST RECOVERY RECTIFIER

Application Ultrafast Recovery times for High Efficiency

Device Types

US1A 50V,1.0A

US1B 100V,1.0A

US1D 200V,1.0A

US1G 400V,1.0A

US1J 600V,1.0A

US1K 800V,1.0A

US1M 1000V,1.0A

See the datasheet for US1A - US1M

DO-41 (Plastic) Axial Lead Plastic Package

ULTRAFAST PLASTIC RECTIFIER

Application Very High Frequency Switching Power Supplies,

Inverters and as Free Wheeling Diodes.

Device Types

UF 4001 50V,1.0A

UF 4002 100V,1.0A

UF 4003 200V,1.0A

UF 4004 400V,1.0A

UF 4005 600V,1.0A

UF 4006 800V,1.0A

UF 4007 1000V,1.0A

See the data sheet for UF4001 - 4007

SOD123FL Surface Mount Plastic Package

GENERAL PURPOSE SILICON RECTIFIER

Applications Glass Passivated Device,Low Reverse

Leakage, Metallurgically Bonded Construction,Automotive

Device Types
DSR 1A 50V,1.0A

DSR 1B 100V,1.0A

DSR 1D 200V,1.0A

DSR 1G 400V,1.0A

DSR 1J 600V,1.0A

DSR 1K 800V,1.0A

DSR 1M 1000V,1.0A

See the data sheet for DSR1A ~DSR1M

DO-201AD SMD Package RoHS compliant

5.0Amp Schottky Barrier Rectifiers

Device Types

SR520 20V,5.0A

SR 540 40V,5.0A

SR 560 60V,5.0A

SR 580 80V,5.0A

SR 5A0 100V,5.0A

SR 5150 150V,5.0A

SR 5200 200V,5.0A

See the data sheet for SR520_SR5200

DO-214AB (SMC) Surface Mount Package

SURFACE MOUNT GLASS PASSIVATED RECTIFIER

Device Types

S3A         50V,3.0A

S3B         100V,3.0A

S3D         200V,3.0A

S3G         400V,3.0A

S3J          600V,3.0A

S3K         800V,3.0A

S3M        1000V,3.0A

See the data sheet for  S3A - S3M

ABS package

1.0Amp BRIDGE RECTIFIERS

Application

SMPS lighting blast adapter battery charger home application.

Device Types

ABS05 50V/1.0AMP

ABS1 100V/1.0AMP

ABS2       200V,1.0Amp

ABS4       400V,1.0Amp

ABS6       600V,1.0Amp

ABS8       800V,1.0Amp

ABS10     1000V,1.0Amp

See the data sheet for ABS05~ABS10

DO-214AC(SMA) Surface Mount Package

Applications: GENERAL RECTIFIER

Device Types

GS1A/M1 50V,1A

GS1B/M2 100V,1A

GS1D/M3 200V,1A

GSG/M4 400V,1A

GS1J/M5 600V,1A

GS1K/M6 800V,1A

GS1M/M7 1000V,1A

See the datasheet for GS1A/M1~ GS1M/M7

DO-214AC (SMA) Surface Mount Package

SURFACE MOUNT SCHOTTKY BARRIER RECTIFIERS

Application:

 Low Voltage, High-Frequency Inverters,

Free Wheeling and Polarity Protection

Device Types
SS22A   20V,2.0A

SS23A   30V,2.0A

SS24A   40V,2.0A

SS25A   50V,2.0A

SS26A   60V,2.0A

SS28A  80V,2.0A

SS210A  100V,2.0A

SS215A 150V,2.0A

SS220A 200V,2.0A

See the datasheet for SS22A-SS220A

SOD-123GW SMD Plastic Package

Low Zener Impedance

Device Types
BZT52C2V0 ~ BZT52C75 500mW

( Zener Voltage 2.0V ~ 75V)

See the data sheet for BZT52CXXX

SOD-123 SMD Plastic Package

Vf < 0.9V at If = 10mA for all Zeners in the MM1Z52XXB Series: 2.7V to 47V

Device Types
MM1Z 5223B
MM1Z 5225B
MM1Z 5226B
MM1Z 5227B
MM1Z 5228B
MM1Z 5229B
MM1Z 5230B
MM1Z 5231B
MM1Z 5232B
MM1Z 5233B
MM1Z 5234B
MM1Z 5235B
MM1Z 5236B
MM1Z 5237B
MM1Z 5238B
MM1Z 5239B
MM1Z 5240B
MM1Z 5241B
MM1Z 5242B
MM1Z 5243B
MM1Z 5244B
MM1Z 5245B
MM1Z 5246B
MM1Z 5247B
MM1Z 5248B
MM1Z 5249B
MM1Z 5250B
MM1Z 5251B
MM1Z 5252B
MM1Z 5253B
MM1Z 5254B
MM1Z 5255B
MM1Z 5256B
MM1Z 5257B
MM1Z 5258B
MM1Z 5258B
MM1Z 5260B
MM1Z 5261B

See the data sheet for MM1Z52XXB Series

DO-35 Hermetically Sealed Glass Axial Package

These devices are also available in SOT-23 (SMD Plastic Package) equivalents as BZX84C Series

NOTE : This device is also available in Defence, HIREL grade, JANXXX, Military Grades

Device Types

BZX55C 2.4V ~ 75V

Applications: Best suited for Industrial, Military and Space Applications.

See the datasheet for BZX55C Series

DO-41 Axial Leaded Package

1 W Silicon Planar Power Zener Diodes

Device Types
1N4727A ~ 1N4761A 3V to 75V Zener

NOTE : This device has Option for screening as per MIL-PRF-19500 for JAN, JANTX, JANTXV and JANS are available by adding CJ,

CX, CV or CS suffix respectively after the part number while ordering.

See the datasheet for 1N47XXA Series

DO-41 Hermetically Sealed Glass Axial Package

Device Types
BZX85C 3V0 ~ C75

APPLICATIONS:

For use in stabilizing and clipping circuits with high power rating..

See the data sheet for BZX85C Series

DO-35 Hermetically Sealed Glass Axial Package

BIDIRECTIONAL TRIGGER DIODE

GLASS PASSIVATED PNPN DEVICE

Applications: For Triggering TRIACs, SCRs, Industrial and Commercial Equipment,

Lamp Dimmer Circuits, Universal Motor Speed Controls, Heat Controls.

Device Types
DB3-22 2A,150mW

See the data sheet for DB3-22

DO-15P Axial Leaded Plastic Package

5W Zener Diode

(Zener Voltage Tolerance is +10% and Suffix 'B' is for +5% Tolerance.)

Application: Barrier Rectifier For Use in : Barrier Rectifier , High Frequency Inverters,

Free Wheeling and Polarity Protection

Device Types

1N5333B (3.3V) 1N5352B(15V) 1N5371B(60V)

1N5334B(3.6V) 1N5353B(16V) 1N5372B(62V)

1N5335B(3.9V) 1N5354B(17V) 1N5373B(68V)

1N5336B(4.3V) 1N5355B(18V) 1N5374B(75V)

1N5337B(4.7V) 1N5356B(19V) 1N5375B(82V)

1N5338B(5.1V) 1N5357B(20V) 1N5376B(87V)

1N5339B(5.6V) 1N5358B(22V) 1N5377B(91V)

1N5340B(6.0V) 1N5359B(24V) 1N5378B(100V)

1N5341B(6.2V ) 1N5360B(25V) 1N5379B(110V)

1N5342B(6.8V) 1N5361B(27V) 1N5380B(120V)

1N5343B(7.5V) 1N5362B(28V) 1N5381B(130V)

1N5344B(8.2V) 1N5363B(30V) 1N5382B(140V)

1N5345B(8.7V ) 1N5364B(33V) 1N5383B(150V)

1N5346B(9.1V) 1N5365B(36V) 1N5384B(160V)

1N5347B(10V) 1N5366B(39V) 1N5385B(170V)

1N5348B(11V) 1N5367B(43V) 1N5386B(180V)

1N5349B(12V) 1N5368B(47V) 1N5387B(190V)

1N5350B(13V) 1N5369B(51V) 1N5388B(200V)

1N5351B(14V) 1N5370B(56)

See the data sheet for 1N53XXB Series

LL-34 Glass Case Mini MELF

Silicon Planer 500mW Zener Rectifier

Applications Low Voltage stabilizers and voltage references

Device Types

BZV55B2V4 to 75V 2% Zeners from 2.4V to 75V

BZV55C2V4 to 75V 5% Zeners from 2.4V to 75V

See the datasheet for BZV55CXX and BZV55BXX

SOD-123 Plastic Package

SILICON EPITAXAL SWITCHING DIODE

Device: 1N4148W, Package: SOD-123GW,

Device: 1N4148WFL, Package: SOD-123FL,

Application Fast Switching

Device Types

1N4148W/1N4148WFL 100V,150mA

See the data sheet for 1N4148W 1N4148WFL

DO-214AC (SMA) Surface Mount Plastic Package

1W SURFACE MOUNT SILICON ZENER DIODE 3.3V to 100V

Application Power Supply, Circuit Protection, SMPS

Device Types

1SMA4728A 3.3 V

1SMA4729A 3.6 V

1SMA4730A 3.9 V

1SMA4731A 4.3 V

1SMA4732A 4.7 V

1SMA4733A 5.1 V

1SMA4734A 5.6 V

1SMA4735A 6.2 V

1SMA4736A 6.8 V

1SMA4737A 7.5 V

1SMA4738A 8.2 V

1SMA4739A 9.1 V

1SMA4740A 10.0 V

1SMA4741A 11.0 V

1SMA4742A 12.0 V

1SMA4743A 13.0 V

1SMA4744A 15.0V

1SMA4745A 16.0 V

1SMA4746A 18.0 V

1SMA4747A 20.0 V

1SMA4748A 22.0 V

1SMA4749A 24.0 V

1SMA4750A 27.0 V

1SMA4751A 30.0 V

1SMA4752A 33.0 V

1SMA4753A 36.0 V

1SMA4754A 39.0 V

1SMA4755A 43.0 V

1SMA4756A 47.0 V

1SMA4757A 51.0 V

1SMA4758A 56.0 V

1SMA4759A 62.0 V

1SMA4760A 68.0 V

1SMA4761A 75.0 V

1SMA4762A 82.0 V

1SMA4763A 91.0 V

1SMA4764A 100.0V

See the data sheet for 1SMA47XX

DO-214AC (SMA) Surface Mount Plastic Package

1.5W SURFACE MOUNT SILICON ZENER DIODE

Application Power Supply, Circuit Protection, SMPS

Device Types

Power- 1.5W

Voltage Range 3.3V ~ 240 V

1SMA5913A (3.3V) ~ 1SMA5957A (240V)

See the data sheet for 1SMA59XX

DO-214AA (SMB) Surface Mount Plastic Package

3W SURFACE MOUNT SILICON ZENER DIODE

Application Power Supply, Circuit Protection, SMPS

Device Types

Power- 3W

Voltage Range 3.3V-200V

1SMB5913A 3.3V

1SMB5914A 3.6V

1SMB5915A 3.9V

1SMB5916A 4.3V

1SMB5917A 4.7V

1SMB5918A 5.1V

1SMB5919A 5.6V

1SMB5920A 6.2V

1SMB5921A 6.8V

1SMB5922A 7.5V

1SMB5923A 8.2V

1SMB5924A 9.1V

1SMB5925A 10V

1SMB5926A 11V

1SMB5927A 12V

1SMB5928A 13V

1SMB5929A 15V

1SMB5930A 16V

1SMB5931A 18V

1SMB5932A 20V

1SMB5933A 22V

1SMB5934A 24V

1SMB5935A 27V

1SMB5936A 30V

1SMB5937A 33V

1SMB5938A 36V

1SMB5939A 39V

1SMB5940A 43V

1SMB5941A 47V

1SMB5942A 51V

1SMB5943A 56V

1SMB5944A 62V

1SMB5945A 68V

1SMB5946A 75V

1SMB5947A 82V

1SMB5948A 91V

1SMB5949A 100V

1SMB5950A 110V

1SMB5951A 120V

1SMB5952A 130V

1SMB5953A 150V

1SMB5954A 160V

1SMB5955A 180V

1SMB5956A 200V

See the data sheet for 1SMB59XXA

SOT-23 Formed SMD Package

SILICON PLANAR HIGH SPEED DIODES

Application  High-Speed Switching Diodes in a Microminiature

Device Types
BAS19 100V,200mA

BAS20 150V,200mA

BAS21 200V,200mA

See the data sheet for BAS19, BAS20, BAS21

SOT-23 Formed SMD Package

SILICON PLANAR SCHOTTKY DIODES

 Application High Speed Switching Diodes

Device Types

BAT54  30V, 200mA

See the data sheet for   BAT54

SOT-23 Surface mounted Plastic Package

SILICON PLANAR SWITCHING DIODE

Application High-Speed Switching Diodes

Device Types

BAS16 75V, 215mA

See the data sheet for BAS16

SOT-23 Formed SMD Package

SILICON PLANAR SWITCHING DIODE

APPLICATIOS  High Speed Switching Diode

Device Types

 CMBD4148     75V, 215mA

See the data sheet for  CMBD4148

SOT-23 Formed SMD Package

SILIICON PLANAR ZENER DIODES

Applications Dual Zener Diodes, Common Anode

Device Types

CZMA3V9-47V 3V9 to 39 V,250mA

See the data sheet for CZMA3V9-47V

Package SOD-323GW (1N4148WS)

Package SOD-323FL (1N4148WSFL)

200mW Fast Switching Diode

Application Fast Switching Diode

Device Types
1N4148WS/WDFL       75V,150mA

See the data sheet for 1N 4148WS 1N 4148WSFL

SOT-23 Surface Mount Package

HIGH-SPEED SWITCHING DIODES

Application High-Speed Switching Series Diode

Device Types

BAV99         100V,215mA

See the datasheet for BAV99

LL-41 (MELF)

1W Zener

Application Stabilising and Clipping Circuits with High Power Rating

Device Types

ZM4727 ~ ZM4761 3V~75V

Applications

For Use in Stabilizing and Clipping Circuits with High Power Rating

See the data sheet for ZM47XX

SOT-23 Surface mount Plastic Package BZX84C Series

SILIICON PLANAR VOLTAGE REGULATOR

These devices are also available in equivalents as DO-35 Hermetically Sealed Glass Axial Package as BZX55C series

Device Types

BZX84C 2V4 to 75V (from 2.4V to 75V)

Applications: Best suited for Industrial, Military and Space Applications.

See the datasheet for BZX84C Series

DO-214AC (SMA) Plastic Package

SURFACE MOUNT GLASS PASSIVATED SILICON RECTIFIERs

Applications General Purpose Rectifiers

Device Types

S1A 50V,1.0A

S1B 100V,1.0A

S1D 200V,1.0A

S1G 400V,1.0A

S1J 600V,1.0A

S1K 800V,1.0A

S1M 1000V,1.0A

See the data sheet for S1A ~S1M

DO-41P Axial Leaded Plastic Package

3W AXIAL LEAD SILICON ZENER DIODES

Application Power Supply, Circuit Protection, SMPS

Device Types

Zener 3W

VZ : 3.9V - 400V

See the data sheet for 3EZ3.9D5 ~ 3EZ400D5

TO- 92 Plastic Package

NPN/ PNP Silicon Planar Epitaxial Transistor

Application Medium Voltage and Current Applications.

Device Types

NPN: CNL635 CPL637 CNL639

PNP: CPL636 CNL638 CPL640

CNL635/ CPL636 : 45V,1A

CNL637/ CPL638 : 60V,1A

CNL639/ CPL640 : 80V,1A

See the data sheet for CNL635_40

TO-92 Plastic Package

NPN SILICON PLANAR TRANSISTOR

Application  General Purpose Audio Amplifier

Device Types

CD9013    30V,500mA

See the data sheet for   CD9013

SOT-23 Formed SMD Package

NPN SILICON PLANAR EPITAXIAL TRANSISTORS

Application General Purpose and Switching Applications

Device Types

BC817 45V 500mA

BC818 25V 500mA

See the datasheet for BC817 BC818

SOT-223 Formed SMD Package

NPN SILICON PLANAR EPITAXIAL TRANSISTORS

Complementary BCP51 BCP52 and BCP53

Application LINEAR VOLTAGE REGULATORS,

LOW SIDE SWITCHING, Inverter,

UPS, Power Supply

Automotive applications

Device Types

BCP54 45V,1A

BCP55 60V,1A

BCP56 80V,1A

See the data sheet forBCP54 BCP55 BCP56

SOT-89

NPN Silicon Planar Epitaxial High Voltage Transistor

Application Automotive, Power Supply, Inverter, Telephone switch etc.

Device Types
MPSA44U 400V, 300mA

See the data sheet for MPSA44U

TO-220F Leaded Plastic Package

Silicon PNP POWER Transistors

Complementary to CSC4793

Application: Power amplifier applications,Driver stage amplifier applications

 Device Types

CSA1837 230V, 1A

See the data sheet for CSA1837 CSC4793

SOT-23 Formed SMD Package

NPN SILICON PLANAR EPITAXIAL TRANSISTORS

Application General purpose switching and automotive applications

Device Types

BC846 65V,100mA

BC847 45V,100mA

BC848 30V,100mA

See the data sheet for BC846 BC847 BC848

SOT-23 SMD Plastic Package

NPN SILICON EPITAXIAL TRANSISTORS

Applications Extremely High Voltage Applications

Device Types
CMBTA42 300V 500mA

CMBTA43 200V 500mA

See the datasheet for CMBTA42 CMBTA43

SOT-23 Formed SMD Package

PNP SILICON EPITAXIAL TRANSISTORS

APPLICATION Professional communication equipment.

Automotive Applications

Device Types

CMBTA92 300V,500mA

CMBTA93 200V,500mA

Equivalents MMBTA92, mmbta93

See the data sheet for CMBTA92 CMBTA93

TO- 92 Plastic Package

PNP /NPN Silicon Planar Epitaxial Transistor

Application Medium Power Voltage and current Amplifier

Device Types
PNP C100/D100 50V 1.0 Amp

See the data sheet for C100_D100

TO- 92 Plastic Package

PNP Silicon Planar Epitaxial Transistor

Application Medium Voltage and Current, Automotive Applications.

Device Types
CPL100 PNP 50V 1.0 Amp

CNL100 NPN 50V,1.0Amp

See the data sheet for CPL100 CNL100

TO- 92 Plastic package

NPN SILICON PLANAR SWITCHING TRANSISTORS

Application:

1. Signal Amplification:

2. Switching Circuits.

3. Logic and Control Circuits.

4.Driving LEDs, controlling motor speed, and controlling the operation of other systems.

5.Oscillator Circuits.

6. Stabilizing or adjusting voltage levels within a circuit.

Device Types
PN2222A, PN2222 40V, 600 mA

See the data sheet for PN2222 PN2222A

TO-126 Leaded Plastic Package

EPITAXIAL SILICON POWER TRANSISTOR

Application High Voltage General Purpose Applications

Device Types

MJE340 NPN 300V / 500mAmp

MJE350 PNP 300V / 500mAmp

See the data sheet for MJE340_350

TO- 92 and SOT-23 Plastic Package

NPN Silicon Planar Epitaxial High Voltage Transistor

Application High Voltage, General Purpose, Telephony

Device Types
2N5551 160V, 600mA

CMBT5551 SOT23 SMD 160V, 600mA

Equivalent: MMBT5551

See the datasheet for 2N5551and for CMBT5551

TO-92 Plastic Package

SILICON PLANAR EPITAXIAL TRANSISTORS

Application Audio Amplifiers, Power Supply

Device Types

BC337/A BC338 NPN

BC327/A BC328 PNP

BC327/337 45V,800mA

BC327A/337A 60V,800mA

BC328/338 25V,800mA

See the data sheet for BC327/A BC328 BC337/A BC338

TO-220 Leaded Plastic Package

6 Amp POWER TRANSISTORS

Application Complementary Silicon Transistors intended for a wide variety of Switching and Amplifier Applications,Series and Shunt Regulators,Driver and Output stages of Hi-Fi Amplifiers.

Device Types

TIP41 TIP42             40V,6A

TIP41A TIP42A        60V,6A

TIP41B TIP42B        80V,6A

TIP41C TIP42C       100V,6A

See the data sheet for  TIP41 A/B/C  TIP42 A/B/C

SOT-23 Formed SMD Package

SILICON EPITAXIAL TRANSISTORS

Application medium power amplification and switching circuit.

Device Types

CMBTA05 60V,500mA

CMBTA06 80V,500mA

See the data sheet for CMBTA05 CMBTA06

TO-92 Leaded Package

PNP SILICON PLANAR TRANSISTORS

Application Audio amplifier stage and convener/inverter.

Device Types

CD8550 25V,2A

See the data sheet for CD8550 B C D

SOT-23 Formed SMD Package

SILICON PLANAR EPITAXIAL TRANSISTORS

Application Switching and linear amplification.

Device Types

CMBT2222 30V,600mA

CMBT2222A 40V,600MA

See the datasheet for CMBT2222 _A

SOT-23 SMD package

NPN SILICON PLANAR EPITAXIAL TRANSISTOR

Application Medium Power Transistor

Device Types
CMMT493 120V, 1Amp

See the data sheet for CMMT493

SOT-23 Surface Mount Plastic Package

NPN SILICON EPITAXIAL TRANSISTORS

Application This device is designed for a general-purpose amplifier and switching applications.

Device Types

CMBT3903 40V,200mA

CMBT3904 40V,200mA

Complimentry of NPN CMBT3903 is PNP CMBT3905

Complimentry of NPN CMBT3904 is PNP CMBT3906

Equivalents : MMBT3903 and MMBT3904

See the datasheet for CMBT3903 _04

TO-92 Plastic Package

NPN SILICON PLANAR EPITAXIAL DARLINGTON TRANSISTORS

Device Types

MPSA13 MPSA14 30V,500mA

See the data sheet for MPSA13 MPSA14

TO- 92 Plastic package

NPN SILICON PLANAR TRANSISTOR

Application Charger, Power conversion, General power switch circuit.

Device Types
CN2222A 40V, 800mAmp

See the data sheet for CN2222A

SOT-23 SMD Plastic Package

PNP SILICON EPITAXIAL TRANSISTORS

Applications : General purpose transistor

Device Types
CMBTA55    60V/500mA

CMBTA56   80V/500mA

See the datasheet for CMBTA55 CMBTA56

SOT-23 SMD Package

PNP SILICON TRANSISTOR

Application

1. Low-Frequency Amplifiers

2. Audio Frequency General Purpose Amplifier Applications

Device Types

CSA1162 50V/150mA

Complementary to 2SC2712

See the data sheet for CSA1162

TO-220 Plastic Package

DARLINGTON PLASTIC POWER TRANSISTORS

Application High Power Switching, Hammer Drive,

Pulse Motor Drive and Inductive Load Drive Applications.

Device Types
TIP120/125 60V,5A

TIP121/126 80V,5A

TIP122/127 100V,5A

See the data sheet for TIP120 _122 TIP125 _127

TO-126 Plastic Package

NPN PLASTIC POWER DARLINGTON TRANSISTORS

1. BD675, 675A, 677, 677A, 679, 679A, 681 are complementary with BD676, 676A, 678, 678A, 680, 680A, 682.

2. BD677, 677A, 679, 679A are equivalent to MJE 800, 801, 802, 803

Application High power switching application

Note: This device is also available in Defence, Miltary, Hirel and JANXXX Grades

Device Types

BD675 BD675A 45V,4.0A

BD677 BD677A 60V,4.0A

BD679 BD679A 80V,4.0A

BD681 100V,4.0A

BD683 120V,4.0A

See the data sheet for BD675,675A,BD677,677A,BD679,679A,BD681,BD683

TO-220 Plastic Package

DARLINGTON PLASTIC POWER TRANSISTORS

Application use in Medium Power Linear and Switching

Device Types
TIP110/115      60V,2A

TIP111/116      80V,2A

TIP112/117     100V,2A

See the data sheet for  TIP110_117

TO-220 Plastic Package

NPN/PNP POWER TRANSISTORS

Application

1.Switching and Amplifier

2. Series and Shunt Regulators

3. Driver and Output stages of Hi-Fi Amplifiers

Device Types

Complementary Silicon Transistors

NPN      BD243       BD243A         BD243B        BD243C

PNP     BD244        BD244A         BD244B        BD244C

            45V,6.0A    60V,6.0A       80V,6.0A      100V,6.0A

See the data sheet for  BD243 BD244

TO-126 Leaded Plastic Package

NPN SILICON POWER TRANSISTORS

Application: Transistor suited for the Output Stage of 3 watt audio amplifier, Voltage

regulator, DC-DC converter and relay driver

Device Types
CSD882 30V, 3 Amp

Complementary PNP CSB772

See the data sheet for CSD882

TO-126 Leaded Plastic Package

PNP Power Transistor

Application Audio Frequency Power Amplifier and Low Speed Switching

Device Types

CSB772P 30V / 3Amp

Complementary CSD882

See the data sheet for CSB772P

TO-220 Leaded Plastic Package

NPN PNP Power Transistors

Application Hi-Fi Amplifier and Switching Regulator

Device Types
MJE2955T NPN 60V/10 Amp
MJE3055T PNP 60V/10 Amp

See the data sheet for MJE2955T MJE3055T

TO-126 Plastic Package

EPITAXIAL SILICON POWER TRANSISTORS

Application Audio Amplifier and Drivers and Automotive applications

Device Types

NPN: BD135, BD137, BD139.

PNP: BD136 BD138, BD140.

BD135/ BD136 45V, 1.5A

BD137/BD138 60V, 1.5A

BD139 /BD140 80V, 1.5A

See the datasheet for BD135 ~ BD140

TO-220 Plastic Package

NPN PLASTIC POWER TRANSISTOR

APPLICATION 1. Medium Power Linear and Switching Service in Consumer, Automotive and Industrial Applications

Device Types

2N6101 70V, 10A

See the data sheet for 2N6101

TO-220 Plastic Package

NPN/PNP POWER TRANSISTORS

Application

1.Switching and Amplifier

2. Series and Shunt Regulators

3. Driver and Output stages of Hi-Fi Amplifiers

Device Types

Complementary Silicon Transistors

NPN BD533 BD535 BD537

PNP BD534 BD536 BD538

            45V,8.0A    60V,6.0A       80V,8.0A

See the data sheet for  BD533_538

TO-126 Leaded Plastic Package

NPN SILICON POWER TRANSISTORS

Application:

Output Stage of 3 watt audio amplifier, Voltage regulator, DC-DC converter and relay driver.

Device Types
CSD882H-P 30V, 3 Amp

Complementary PNP CSB772

See the data sheet for CSD882H-P

DO-214AC (SMA) SMD Plastic Package

Device Types
Breakdown Voltage: 6.8 to 600 V

Peak Pulse Power: 400 W

See the data sheet for  P4SMAXXA/CA

DO-15 Axial Leaded Plastic Package

600W Transient Voltage Suppressor

APPLICATION: Protection of I/O Interfaces,

VCC bus and other vulnerable circuits used in telecom,computer,

Industrial and consumer electronic applications.

Device Types
P6KEXXX 600W 6.8 VA/CA- 600V A/CA

See the datasheet for P6KEXXX

DO-214AA (SMB) SMD Plastic Package

Device Types
SMBJXX (6.4 V ~ 7 V ) to (492V ~ 543V) SMBJXX

See the datasheet for SMBJXX

SOD-123FL Plastic Package

200W Transient Voltage Suppressor

Applications

It’s applications are in cellular phones, portable devices, business machines, power supplies and many other industrial/consumer applications.

Device Types

SMF5.0A /CA ~ SMF190A /CA

VRWM: 5.0V ~ 190.0V

See the data sheet for SMFXXXA /CA

DO-214AB(SMC) Surface Mount Package

1500W SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSORS

Device Types
Reverse Voltage 5.0 ~ 550 V

APPLICATIONS:

Protection of I/O Interfaces, VCC bus and other vulnerable circuits used in telecom, computer, Industrial and

consumer electronic applications

See the data sheet for SMCJXXX

DO-201AD Leaded Plastic Package

1.5KE6.8 - 1.5KE600A Breakdown voltage range: 6.8V ~ 600V

1500W PEAK POWER TRANSIENT VOLTAGE SUPPRESSORS

Application: Excellent Clamping Capability, Fast response time, TVS

NOTE: This device is also available in Defence/ Miltary, HIREL, JANXXX Grades

Device Types

1.5KE6.8A/CA~1.5KE440A/CA

See the data sheet for 1.5KE6.8A/CA - 1.5KE600A/CA (1500W)

DO-214AB(SMC) Surface Mount Plastic Package

3000W Surface Mount Transient Voltage Suppressors

Device Types

Reverse Voltage 5.0 ~ 440 V,

APPLICATIONS:

Protection of I/O Interfaces, VCC bus and other vulnerable circuits used in telecom,computer, Industrial and consumer electronic applications

See the data sheet for SMDJXXX

ESD Protection Diode Array

SOT 23 Surface Mount Package

 Application:

1. Data line

2. Automatic Teller Machines

3. Net works.

4. Power line.

Device Types

SM712 ESD Protection Diode Array

See the data sheet for SM712

DO-214AC(SMA) Surface Mount Package

Application: Transient protections in Single phase, half wave, 60Hz, for resistive or Inductive.and Capacitive Load.

SMAJ5.0A/CA 5V

to

SMAJ440A/CA 440V

Equivalent : P4SMAJxxxA/CA Series

See the datasheet for SMAJXXXA/CA

DO-218AB Surface Mount Package

Surface Mount Transient Voltage Suppressors

Application Protection of I/O Interfaces, VCC bus and other vulnerable

circuits used in telecom,computer, Industrial and consumer electronic applications.

Device Types

SM8SXX 6600W, 700A 10V~40V

See the datasheet for SM8SXX

DO-41P Axial Leaded Plastic Package

Glass Passivated Junction Transient Voltage Suppressor Rectifiers

APPLICATION:

1. Communication Systems

2. Power Supplies

3. Medical Equipment

4. Business Machines

Device Types
P4KEXXX series

Reverse Voltage 5.8 ~ 509 V

400 Watt Peak Pulse Power

See the datasheet for P4KEXXX series

DO-214AB(SMC) Surface Mount Plastic Package

Surface Mount Transient Voltage Suppressor Rectifiers

Device Types
Reverse Voltage 5.0 V ~ 440V

APPLICATIONS:

Protection of I/O Interfaces, VCC bus and other vulnerable circuits used in telecom, computer, Industrial and

consumer electronic applications

See the data sheet for 5.0SMDJXXX
